Woven technical fabric production at a partner mill

Air Slide Fabric & Aeration Pads

Polyester woven fabric that keeps powder flowing — air slides, silo aeration and tanker discharge.

High, evenly distributed air permeability along the full length
Wear-resistant weave for abrasive powder duty
Supplied cut to length, or sewn as endless belts
Companion aeration pads made to drawing

Polyester woven
Uniform permeability
Widths to 1.2 m
Cut to length

Request a Quote Specifications ↓

Overview

What This Product Is

Air slide fabric is the quiet hero of powder handling: sandwiched in an air slide chute, it lets low-pressure air pass evenly upward to fluidize the powder, so cement, alumina or fly ash flows down a slight incline like a liquid. If the fabric's permeability is uneven or it has blinded with moisture, the powder stalls and the whole conveying line stops.

We supply woven polyester air slide fabric cut to your channel width and length, sewn endless belts where the installation takes them, and aeration pads made to drawing for silo bottoms and hoppers. For mobile duty — bulk cement tankers — the same fabric is supplied cut to the trailer's aeration grid, a common replacement item for fleet operators.

Specifications

Typical Values

Typical industry values — the exact specification for your order is confirmed in the quotation.

Item	Typical Spec	Key Property	Typical Use
Air slide fabric (standard)	≈ 400 g/m²	Uniform fluidizing permeability	Air slide chutes, conveying
Air slide fabric (heavy duty)	≈ 480 g/m²	Higher wear resistance	Abrasive powder duty
Aeration pad	Made to drawing	Even air distribution	Silo bottoms, hoppers, tankers

Typical values — width, thickness and permeability are confirmed per specification.

Applications

Where It Works

Cement plants — air slides, silo aeration, mill outlet
Bulk cement tankers — trailer aeration grids (fleet replacement)
Alumina and fine powder handling
Fly ash and mineral powder conveying

Customization

Made to Your Specification

Width to your channel; cut to length or endless belt
Thickness and density for your abrasion duty
Aeration pads to drawing, with fixing layout on request
Consistent roll-to-roll permeability for multi-chute plants

FAQ

Common Questions

How do I order the right size?

Send the channel's inner width and the length per section (or the full run), and whether the installation takes an endless belt. We cut accordingly and confirm before production.

Why did my previous fabric blind early?

The usual causes are moisture in the conveying air and oil carry-over from the blower — not the fabric itself. Keep the air dry and oil-free; if the problem persists, send us the used fabric and we will read the failure mode.

Do you supply tanker replacement fabric?

Yes — cut to the aeration grid of common bulk cement trailer layouts, or to your drawing for fleets.
